| Specification | Description |
|---|---|
| Maximum Grinding | 15.75" x 31.5" |
| Max Longitudinal Grind | 32" |
| Max Cross Grind | 16" |
| Max Distance Table to Spindle | 24.75" |
| Motor Speed (60 Hz) | 1,750 RPM |
| Spindle Motor | 5 HP |
| Longitudinal Table Travel | |
| Hydraulic | 33.4375" |
| Hand | 35.375 |
| Cross Transverse Travel | |
| Automatic Transverse Increments | 1/8" - 1.25" |
| Max Automatic Transverse Travel | 16" |
| Hand Feed per Revolution | 0.25" |
| Graduation of Handwheel | 0.0025" |
| Vertical Hand Wheel Infeed | |
| Automatic Infeed | 0.00005" - 0.002" |
| Wheel Diameter | 12" (60 Hz) / 14" (50 Hz) |
| Wheel Width | 1.5" |
| Total Spce Required | 132" x 68" x 88" (H) |
| Weight | 6,500 Lbs |
